CM6241/41V Ordinary Lathe

Get a quote

Download file

Features
Parameters
Configuration

Data is being organized...

Model		CM6241×1000/1500	CM6241V×1000/1500
Processing Range	Maximum workpiece swing diameter over bed	410mm(16＂)
	Maximum workpiece swing diameter over carriage	255mm(10＂)
	Maximum swing diameter in gap	580mm(23＂)
	Effective length of apron in front of face plate	190mm(7-1/2＂)
	Distance between centers	1000mm(40＂)/1500mm(60″)
	Spindle center height	205(8″)
	Bed width	250(10＂)
Spindle	Spindle nose	D1-6
	Spindle bore	52mm(2＂)
	Spindle bore taper	No.6Morse
	Spindle speed range	16 changes 45-1800r/min	30-550r/min or 550-3000r/min
Feed and Thread	Maximum longitudinal travel of top slide	140mm(5-1/2＂)
	Maximum cross travel of cross slide	210mm(8-1/4＂)
	Leadscrew specification	6mm or 4T.P.I.
	Maximum size of tool shank (width × height)	20×20mm(13/16＂)
	Longitudinal feed range	0.05-1.7mm/rev(0.002＂-0.067＂/rev)
	Cross feed range	0.025-0.85mm(0.001＂-0.0335＂/rev)
	Metric thread range	39kinds 0.2-14mm
	Imperial thread range	45kinds 2-72T.P.I
	Diametral pitch thread specification	21kinds 8-44D.P.
	Module thread specification	18kinds 0.3-3.5M.P.
Tailstock	Tailstock quill diameter	50mm(2＂)
	Tailstock quill travel	120mm(4-3/4＂)
	Taper of tailstock quill bore	No.4 Morse
	Transverse adjustment	±13mm(±1/2＂)
Motor	Main motor power	2.2/3.3kW(3/4.5HP)3PH
	Coolant pump power	0.1kW(1/8HP),3PH
Overall dimensions and weight	Overall dimensions (L×W×H)	194×85×132cm	244×85×132cm
	Packing dimensions (L×W×H)	206×90×164cm	256×90×164cm
	Net weight/Gross weight	1160kg/1350kg	1340kg /1565kg

Standard Accessories

• Reducing sleeve
• Dead center
• 3-jaw chuck
• 4-jaw chuck
• Faceplate
• Steady rest
• Follow rest
• Change gears
• Machine tool box (including a set of tools)
• Bed base
• Work lamp
• Foot brake
• Cooling

Special Accessories

• Live center
